Description
Summary
The HRU-3601A is a cost-effective indoor LoRa t&h (temperature and humidity) monitor that enables remote environmental monitoring by wirelessly uploading recorded data to a cloud server. This device utilizes LoRaWAN communication technology, which ensures a broad transmission range while maintaining low power consumption. With its exceptional precision and lightweight design, the HRU-3601A is easy to install and configure, making it an ideal solution for indoor use in homes, industrial settings, and other indoor environments.
Main Features
- ESP32-C3FN4 + SX1262.
- Support Wi-Fi, LoRa/LoRaWAN.
- The power supply voltage: USB Type-C 5V.
- Small size, exquisite appearance.
- High sensitivity, High precision, Low power consumption.
- Recommend operating temperature range: -20°C to 50°C .
- Remote monitoring can be realized,available on the server.
- Monitorable data temperature and humidity(3601A).
- Support OTA upgrade.
Specifications
| Parameters | Description | MCU | ESP32-C3FN4 |
|---|---|
| LoRa Chip | SX1262 |
| WiFi | 802.11 b/g/n |
| LoRa Frequency | 863～870MHz, 902～928MHz, 470～510MHz |
| Storage Temperature | -40~85℃ |
| Operating Temperature | -20~50℃ |
| Push Interval | 2 Minutes(min) |
| Supply Voltage | USB-TypeC 5V |
| Operating Humidity | 90%RH(Non Condensing) |
| Sensor Module | GXHTV3 |
Description
Easy config
Power on
Scan and register
Dislpay
High light
FAQ
- When the power is just on, the overall temperature of the equipment is high, and after 1 to 2 hours, the equipment returns to normal.
- The LoRaWAN gateway is not successfully connected to the network, and the device temperature will increase.
NO. This device is a LoRaWAN protocol and must be connected to the network through a LoRaWAN gateway.
The device retains a lithium battery port, but it requires you to pry open the case, and the interior is too small to hold most batteries.
Docs & Resource
- [Resource] — Heltec LoRaWAN test server based on TTS V3
- [Resource] — Datasheet
- [Docs] —Operation User Manual
- [Resource] —Downloadable Resources
Packing list
The default packing list without selecting any accessories is as follows:
| Item | Quantity |
|---|---|
| HRU-3601 | x1 |
| Type-C Cable | x1 |
| Power Adapter | x1 |
Characteristics
| Weight | 60 g |
|---|---|
| Dimensions | 8.8 × 8.8 × 2.5 cm |
| LoRa Band | 433MHz, 470~510MHz, 863~870MHz, 902~928MHz |
| 3601 Option | 3601A, 3601B |
