1.3” OLED Display

$4.90 – $5.60



note

accessories

reseller

  • We highly recommend the External Charge Pump Version, it is the most stable version. The PCB of the External Charge Pump Version is green.

Clear
Category: SKU: ZC-06-W Tags:

Related products

1.3″ OLED display module with I2C (or SPI) interface (10K pull-up resistance already included in I2C bus), SH1106 driver chip, internal or external charge pump optional, elliptical fixed hole (fit M2 screw), we also left a 1.0 x 4 FFC socket footprint on board, It’s a well-established product and had been used in many situations.

This product can’t meet your needs? Choose from our  OLED Family.

IIC白色1.3
IIC蓝色1.3
1.3iicb
1.3iic_800x800

1.3 inch OLED is a part of the “OLED Display“ series, with the following features:

  • Display Resolution: 128 x 64;
  • On board power-on auto reset circuit;
  • Internal / External charge pump optional (for OLED panel power supply);
  • I2C (2.54 x 4) or SPI (2.54 x 6) interface optional;
  • 1.0 x 4 FFC footprint (I2C only);
  • Default I2C address: 0x3C, for some MCU with 8-bit I2C register, the I2C address should be 0x78 (0x3C << 1).

Technical Parameters

Source Parameter
Driver Chip SH1106
Working Temperature -30 ~ 80 ℃
Color White, Blue
Power Supply 2.5V ~ 6V
Interface SPI (2.54 x 6) or IIC (2.54 x 4) optional
Display Resolution 1.3 inch, Dot 128×64
Size 35.5 x 32 x 3.6 mm

DataSheet & User Manual

1.3" OLED Arduino Example Code

We highly recommend use “u8g2” library, search “u8g2” in Arduino library manager and install:

AutoCAD 2017 Outline Drawing

AutoCAD 2017 Outline Drawing: https://resource.heltec.cn/download/oled/OLED.dwg

Heltec OLED Display product Difference Table (Selection Table)

https://docs.heltec.cn/#/en/products/display/oled/heltec_oled_display_list_eu

Heltec OLED Display Common Problem Summary

https://resource.heltec.cn/download/oled/OLED_Common_Problems_V0.1.pdf

Want Buy some OLED Display without PCB?

https://heltec.org/product/oled-no-pcb/

Over View

1.3 inch OLED is a part of the “OLED Display“ series, with the following features:

  • Display Resolution: 128 x 64;
  • On board power-on auto reset circuit;
  • Internal / External charge pump optional (for OLED panel power supply);
  • I2C (2.54 x 4) or SPI (2.54 x 6) interface optional;
  • 1.0 x 4 FFC footprint (I2C only);
  • Default I2C address: 0x3C, for some MCU with 8-bit I2C register, the I2C address should be 0x78 (0x3C << 1).
Tech Specs

Technical Parameters

Source Parameter
Driver Chip SH1106
Working Temperature -30 ~ 80 ℃
Color White, Blue
Power Supply 2.5V ~ 6V
Interface SPI (2.54 x 6) or IIC (2.54 x 4) optional
Display Resolution 1.3 inch, Dot 128×64
Size 35.5 x 32 x 3.6 mm
Docs & Resource

DataSheet & User Manual

1.3" OLED Arduino Example Code

We highly recommend use “u8g2” library, search “u8g2” in Arduino library manager and install:

AutoCAD 2017 Outline Drawing

AutoCAD 2017 Outline Drawing: https://resource.heltec.cn/download/oled/OLED.dwg

Heltec OLED Display product Difference Table (Selection Table)

https://docs.heltec.cn/#/en/products/display/oled/heltec_oled_display_list_eu

Heltec OLED Display Common Problem Summary

https://resource.heltec.cn/download/oled/OLED_Common_Problems_V0.1.pdf

Want Buy some OLED Display without PCB?

https://heltec.org/product/oled-no-pcb/
