HT-M00 Dual Channel LoRa Gateway

$45.00 $39.00

note

accessories

reseller

  • Built in antenna.
  • Include HT-M00 wall bracket.
  • Type-C cable(Not include AC / DC converter)
  • There are no accessories for the time being.

Clear
Category: SKU: N/A Tags:

HT-M00 is a low-cost dual channel gateway.It is located to smart family LoRa applications that work with less than 30PCS LoRa nodes.This gateway is based on two SX1276 chips driven by ESP32. We wrote a software mixer (also called a baseband simulation program) to make it possible to achieve 125KHz SF7~SF12 spreading factor monitoring.

This product can’t meet your needs? Choose from our LoRa Gateway Family.

HT-M00 Dual Channel LoRa Gateway is a part of the “Heltec LoRa“ series, with the following features:

  • CE Certificate
  • ESP32 + SX1276
  • Size: 75 x 30 x 13mm
  • Emulates LoRa demodulators
  • Automatic adaptive spread spectrum factor, SF7 to SF12 for each channel is optional
  • Maximum output: 18 ± 1dBm
  • Communication interface Type-C USB
  • The power supply voltage:5V
  • Support for LoRaWAN Class A, Class C protocols
  • Frequency range:
    • Europe – 868MHz ISM band (863MHz to 870MHz range)
    • Europe – 433MHz ISM band
    • USA/Australia – 915MHz ISM band (902MHz to 928MHz range)
    • China – 470MHz ISM band (470MHz to 510MHz range)

Technical Parameters

source Parameter
Main control chip esp32
LoRa RF chip SX1276
Working Band (optional) EU_433, CN_470_510, EU_863_870, US_902_928
LoRa maximum output power 18dB ± 1dB
Receiving sensitivity
Interface USB Type-C x 1
USB to Serial chip CP2102
size 75 x 30 x 13mm
Working temperature -40 ~ 80 ℃

Electrical characteristics

Electrical characteristics condition Minimum Typical Maximum
Power Supply USB power supply (≥500mA) 4.8V 5V 6V
Power consumption(mA) 2 Channel Listening (Receive mode)
LoRa 10dB Output
LoRa 12dB Output
LoRa 15dB Output
LoRa 20dB Output

Heltec LoRa Gateway Porducts Difference Table (Product Selection Table)

3D Drawing

How to Use HT-M00 Connect to The Thing Network

LoRaWAN Frequency Plans and Regulations by Country.

Over View

HT-M00 Dual Channel LoRa Gateway is a part of the “Heltec LoRa“ series, with the following features:

  • CE Certificate
  • ESP32 + SX1276
  • Size: 75 x 30 x 13mm
  • Emulates LoRa demodulators
  • Automatic adaptive spread spectrum factor, SF7 to SF12 for each channel is optional
  • Maximum output: 18 ± 1dBm
  • Communication interface Type-C USB
  • The power supply voltage:5V
  • Support for LoRaWAN Class A, Class C protocols
  • Frequency range:
    • Europe – 868MHz ISM band (863MHz to 870MHz range)
    • Europe – 433MHz ISM band
    • USA/Australia – 915MHz ISM band (902MHz to 928MHz range)
    • China – 470MHz ISM band (470MHz to 510MHz range)
Tech Specs

Technical Parameters

source Parameter
Main control chip esp32
LoRa RF chip SX1276
Working Band (optional) EU_433, CN_470_510, EU_863_870, US_902_928
LoRa maximum output power 18dB ± 1dB
Receiving sensitivity
Interface USB Type-C x 1
USB to Serial chip CP2102
size 75 x 30 x 13mm
Working temperature -40 ~ 80 ℃

Electrical characteristics

Electrical characteristics condition Minimum Typical Maximum
Power Supply USB power supply (≥500mA) 4.8V 5V 6V
Power consumption(mA) 2 Channel Listening (Receive mode)
LoRa 10dB Output
LoRa 12dB Output
LoRa 15dB Output
LoRa 20dB Output
Docs & Resource

Heltec LoRa Gateway Porducts Difference Table (Product Selection Table)

3D Drawing

How to Use HT-M00 Connect to The Thing Network

LoRaWAN Frequency Plans and Regulations by Country.

Test Info
