Description
Summary
HT-DE01 is a universal driver board for E-Ink, which is compatible with E-Ink for most 24 pin FFC interface. It uses ESP32-S3FN8 as the main chip and provides the communication mode of Bluetooth and Wi-Fi.
It is also used as an Arduino development board, We provide the development environment and sample code, So that you can do the corresponding development work.
Main Features
- The MCU uses ESP32-S3FN8, supports Wi-Fi and BLE.
- Integrated USB to serial chip, facilitate user secondary development.
- Supports Arduino.
- Provides a development environment and sample code.
- Storage temperature range: -40 ~ 85℃
- Onboard SH1.25-2 battery interface, integrated lithium battery management system (charge and discharge management, overcharge protection, battery power detection, USB / battery power automatic switching).
Specifications
| Parameters | Description |
|---|---|
| MCU | ESP32-S3FN8(Xtensa® 32, dual-core processor, 240MHz) |
| UART Chip | CP2102 |
| Storage Temperature | -40~85℃ |
| Recommended Operating Temperature | -10~55℃ |
| Power Supply | SH1.25-2 lithium battery USB Type-C 5V |
| Wi-Fi Protocol | IEEE 802.11b/g/n |
| BLE | Bluetooth 5; Bluetooth mesh |
| E-Ink Interface | Interface 24 pin FFC |
| Communication Mode | Wi-Fi, Bluetooth |
| Dimensions | 49mmx25mm |
High light
Showing Slide 1 of 3
Packing list
The default packing list without selecting any accessories is as follows:
| Item | Quantity |
|---|---|
| Multi Size E-ink Drive Board | x1 |
Characteristics
| Weight | 6.1 g |
|---|---|
| Dimensions | 4.9 × 2.5 × 0.85 cm |
| Solar Panel Option | Solar Panel for Snesor Hub, Solar Panel for Battery |
No Reviews
Multi Size E-ink Drive Board
What's this?
It is e-ink driveboard, the accessory of E-ink display.
$9.90
Out of stock
