Sale!
HT-M01 Mini LoRa Gateway
$240.00 $135.00
note
accessories
reseller
- Not include battery;
- HT-M01 to RPI Special converter
- Raspberry Pi Zero W
- Better antenna;
- Micro TF card.
Related products
-
HT-M02 Edge LoRa Gateway $400.00 – $499.00 -
Turtle Board$33.00$29.80 -
LoRa Kit 151$14.00$11.80 -
WiFi LoRa 32 (V2) $18.20 – $20.80
HT-M01 is a picocell LoRa gateway based SX1301 baseband chip, it’s must work with other operating systems (Windows® or Linux), when we designed it, we define this product positioning is convenient user authentication LoRa communication scheme. HT-M01 support both SPI and USB interface can work with Windows® (7, 8, 10 or higher) or Linux (Raspberry Pi®). With well-designed structure, the great heat from SX1301 can be transfer to the Aluminum shell, makes HT-M01 works more stable than other products of the same type.
This product can’t meet your needs? Choose from our LoRa Gateway Family.
HT-M01 Mini LoRa Gateway is a part of the “Heltec LoRa“ series, with the following features:
- CE Certificate
- SX1301 digital baseband chip
- Size: 66(+10) x 30 x 15mm (can assemble with raspberry pi ZERO via a special converter board)
- Emulates 49x LoRa demodulators and 1x (G)FSK demodulator
- 10 programmable parallel demodulation paths
- Dynamic data-rate adaptation (ADR)
- Automatic adaptive spread spectrum factor, SF7 to SF12 for each channel is optional
- Maximum output: 20 ± 1dBm
- Up to -139dBm sensitivity with SX1257 or SX1255 Tx/Rx front-end
- Communication interface SPI or USB
- The power supply voltage:5V
- Support for LoRaWAN Class A, Class B, Class C protocols
- Through the unique heat conduction device to transfer heat to the aluminum housing, strengthen heat dissipation, make the operation more stable
- -20°C to 70°C maximum operating temperature range
- Frequency range:
- Europe – 868MHz ISM band (863MHz to 870MHz range)
- Europe – 433MHz ISM band
- USA/Australia – 915MHz ISM band (902MHz to 928MHz range)
- China – 470MHz ISM band (470MHz to 510MHz range)
Technical Parameters
| source | Parameter | |
| LoRa Baseband chip | SX1301 | |
| LoRa RF chip | SX1255(EU_433, CN_470_510)；SX1257（EU_863_870, US_902_928） | |
| Working Band (optional) | EU_433, CN_470_510, EU_863_870, US_902_928 | |
| LoRa maximum output power | 20dB ± 1dB | |
| Receiving sensitivity | -142.5dBm @ 300bps | |
| Interface | Micro USB x 1; SPI x 1; LoRa Antenna (SMA) x 1; | |
| USB to SPI bridge chip | STM32F401CEU6 | |
| size | 66(+10) x 30 x 15 mm | |
| Working temperature | -40 ~ 80 ℃ | |
Electrical characteristics
| Electrical characteristics | condition | Minimum | Typical | Maximum |
| Power Supply | USB power supply (≥500mA) | 4.8V | 5V | 6V |
| 2.54 x 4 x 2 header power supply（≥500mA） | 4.8V | 5V | 6V | |
| Power consumption(mA) | 8 Channel Listening (Receive mode) | 312mA | ||
| LoRa 10dB Output | 254mA | |||
| LoRa 12dB Output | 258mA | |||
| LoRa 15dB Output | 259mA | |||
| LoRa 20dB Output | 284mA |
Pin Definition
| Pin | Description |
| VCC | +5V power supply |
| GND | +5V GND |
| MOSI | SPI bus data for SX1301 |
| MISO | SPI bus data for SX1301 |
| SCK | SPI clock for SX1301 |
| CS | Chip select (LOW select) |
| PRST | SX1301 reset pin (Keep this pin HIGH over 10ms, SX1301 reset) |
| NRST | USB-SPI converter IC disable pin (when working in SPI, Keep this pin LOW all the time) |
HT-M01 User Manual
HT-M01 Relative Source code
All the following code are tested with Raspberry PI:
- Source code for SPI mode
- Driver/HAL for HT-M01: https://github.com/Lora-net/lora_gateway
- Forwards RF packets receive by the HT-M01 to a server through a IP/UDP link, and emits RF packets that are sent by the server: https://github.com/Lora-net/packet_forwarder
- Scripts running on Raspberry PI, Create an auto run process/services for HT-M01 (process name: lrgateway), need “lora_gateway” and “packet_forwarder” both work correctly: https://github.com/HelTecAutomation/lorasdk
- Source code for USB mode
- USB Driver/HAL for HT-M01: https://github.com/Lora-net/picoGW_hal
- Forwards RF packets receive by the HT-M01 to a server through a IP/UDP link, and emits RF packets that are sent by the server: https://github.com/Lora-net/picoGW_packet_forwarder
- Scripts running on Raspberry PI, create an autorun process/services for HT-M01 (process name: lrgateway), need “picoGW_hal” and “picoGW_packet_forwarder” both work correctly: https://github.com/HelTecAutomation/picolorasdk
Graphical User Interface running on Windows®
- GUI Demo App (From Semtech®)
- User Manual for GUI Demo App.
PicoGW Tools Can't Choose China configration?
Heltec LoRa Gateway Porducts Difference Table (Product Selection Table)
3D Drawing
Solid Works 2014 Version 3D Drawing: http://resource.heltec.cn/download/HT-M01/ht-m01_solidworks.zip
How to Use HT-M01 Connect to The Thing Network
Highly Recommend Private Open-source LoRa Server Solution
Quickstart on Debian or Ubuntu server: https://www.loraserver.io/guides/debian-ubuntu/
:
LoRaWAN Frequency Plans and Regulations by Country.
470MHz SWR Test Data
LoRa 470MHz RF Power Output
LoRa 868MHz RF Power Output
LoRa 915MHz RF Power Output
The Power consumption of 8 Channel Listening (Receive mode)
