Wireless Stick Lite (Panda Board) Phaseout

$15.90

    Category: SKU: N/A Tags:

    Related products

    Many users need a version without OLED display, because they want to use it directly in their IoT projects as the main controller and RF (LoRa, Wi-Fi, BLE) connection. Compare with Wireless Stick, “Wireless Stick Lite” has much better low power design (30uA in deep sleep). Removed the 0.49″ OLED, use ESP32-PICO MCU (it’s more friendly for low power design),

    This product can’t meet your needs? Choose from the Heltec Products Selecter.

    P1010581_800X800
    P10106101
    P1010580_800X800

    Wireless Stick Lite is a part of the “Heltec LoRa“ series, with the following features:

    • CE Certificate;
    • Microprocessor: ESP32-PICO (dual-core 32-bit MCU + ULP core + Internal 4MB FLASH), with LoRa node chip SX1276;
    • Micro USB interface with a complete voltage regulator, ESD protection, short circuit protection, RF shielding, and other protection measures;
    • Onboard SH1.25-2 battery interface, integrated lithium battery management system (charge and discharge management, overcharge protection, battery power detection, USB / battery power automatic switching);
    • Integrated WiFi, LoRa, Bluetooth three network connections, onboard Wi-Fi, Bluetooth dedicated 2.4GHz metal 3D antenna, reserved IPEX (U.FL) interface for LoRa;
    • Integrated CP2102 USB to serial port chip, convenient for program downloading, debugging information printing;
    • Support the Arduino development environment;
    • (Exclusive) Supports the Arduino version of the ESP32 + LoRaWAN protocol routine provided by Heltec. This is a standard LoRaWAN protocol that can communicate with any gateway/base station running the LoRaWAN protocol (requires serial number activation, only the development of the company) The board is available, the serial number can be queried on this page);
    • With good RF circuit design and good low-power design (sleep current ≤ 30uA), it is convenient for IoT application vendors to quickly verify solutions and deploy applications;
    Download

    How to install Heltec ESP32 Arduino Development Environment

    http://www.heltec.cn/wifi_kit_install/

    Wireless Stick Lite Source code

    Heltec ESP(ESP32 & ESP8266) framework (the basic of Heltec ESP series products Arduino running environment): https://github.com/Heltec-Aaron-Lee/WiFi_Kit_series



    Heltec ESP32 library (must work with Heltec ESP framework): https://github.com/HelTecAutomation/Heltec_ESP32



    Heltec ESP32 LoRaWAN library (a standard LoRaWAN protocol library provide by Heltec Automation, need a license to active: http://www.heltec.cn/search/): https://github.com/HelTecAutomation/ESP32_LoRaWAN

    Wireless Stick Lite Schematic Diagram

    The schematic diagram of Wireless Stick Lite is restricted technical data, it will become downloadable after purchase.You can learn how to get the schematic diagram through this document: https://heltec-automation-docs.readthedocs.io/en/latest/general/view_limited_technical_data.html.(Didn’t buy this product from our website or from a reseller? You can contact your provider or Email us)

    Wireless Stick Lite Pin out Diagram

    https://resource.heltec.cn/download/Wireless_Stick_Lite/Wireless_Stick_Lite.pdf

    Wireless Stick Lite Pin out Diagram

    https://resource.heltec.cn/download/Wireless_Stick_Lite/Wireless_Stick_Lite.pdf

    Heltec LoRa Node Porducts Difference Table (Product Selection Table)

    https://docs.heltec.cn/#/en/products/lora/lora_node/heltec_lora_node_list_eu
