HRU-1000 is a wireless thermoprobe, which collect the temperature data to display on the built-in screen or upload it to the LoRaWAN network. It has the
characteristics of high precision, long transmission distance and low power consumption, and easy configuration via Bluetooth.
HRU-1000 is integrated with 800mAh rechargeable battery. Benefits from the IP66 protection provided by high-strength plastics and stainless steel, it is stable and excellent in various industrial scenarios.
Main Features
- Temperature range -40~200℃, optimal accuracy ±1℃
- Support LoRaWAN, configure via BLE.
- Recommended Working humidity: ≤90% (non-condensing).
- Wireless data transmission communication radius up to 1.5~3km (noocclusion)
- Built-in 800mAh rechargeable lithium battery, charging voltage 5V DC, long endurance.
- Pen-shaped structure, easy to carry.
- Stainless steel probe and high strength plastic for a variety of scenarios.
Specifications
Parameters | Description | Temperature Measuring Range | -40 ~ 200 °C |
---|---|
Accuracy | ±0.5°C |
Display | 0.96inch LCD |
Max. Receiving Sensitivity | -135dBm@SF12 BW=125KHz |
LoRa Max. TX Power | 20 ± 2 dBm |
Signal Range | 3km (depending on gateway antenna and environments) |
IP Rating | IP65 |
Dimension | L: 335mm,φ28×4.5mm |
Operating Humidity | 10% ~ 100%, no-condensing |
Battery Capacity | 800mAh |
Charging Voltage | 2.5mm-2P Magnetic to USB 5V |
Easy config
Step. 1
Step. 2
Step. 3
Power on
Scan and register
Display
High light
Low-power consumption
Low-power consumption, rechargeable battery, magnetic suction charging interface, Send up to 80 thousand times per charge.
FAQ
We provide complete stainless steel temperature probes that are expertly constructed using spun and welded stainless steel probe ends. Our probes are compatible with the most prevalent temperature controllers and home brewery automation systems available in the market.
Our temperature probes are made from high-quality stainless steel, ensuring that they are durable and long-lasting. Additionally, they are assembled by our team of experts, who guarantee that each part is carefully constructed to meet your specific needs.
Whether you are a home brewer or a commercial brewery, our temperature probes will deliver precise and accurate temperature readings, allowing you to achieve consistent and high-quality results every time.
We are committed to providing top-of-the-line temperature probes that are reliable and easy to use. If you have any questions or require further information, please do not hesitate to contact us.
To create high-quality and delicious beer, brewers must ensure that their brewing equipment is clean and well-maintained. Therefore, it is crucial to regularly and carefully clean all the tanks and pipes that make up the brewing system. In the past, this was done manually, but nowadays, many breweries use automated Clean in Place (CIP) processes to clean and maintain their equipment. This is true for breweries of all sizes, from large commercial operations to small independent craft breweries.
The device has been built with an rechargeable battery, enabling free and unimpeded utilization of the device without the need for any additional circuit boards.
Docs & Resource
[Resource] — Datasheet
[Docs] — User Manual
Packing list
The default packing list without selecting any accessories is as follows:
Item | Quantity |
---|---|
Wireless Thermoprobe | x1 |
Add an Accessories
Recommend accessories for Wireless Thermoprobe
Related products
-
Wifi Kit 8 $7.59
-
HT1303 LoRaWAN Concentrator Module
$89.00Original price was: $89.00.$49.00Current price is: $49.00.
Characteristics
Weight | 50 g |
---|---|
Dimensions | 34 × 3 × 3 cm |
LoRa Band | AS923_1MHz, AS923_2MHz, AU915MHz, CN470MHz, EU868MHz, IN865MHz, KR920MHz, US915MHz |
